Market dynamics are driving innovations in the commercial cooling market with manufacturers blurring the lines between new technologies and traditional applications. Andre Patenaude of Emerson Climate Technologies delivers some winning combinations.

CO2 and ammonia are two natural refrigerants that have historically played predictable roles in refrigeration.
Ammonia (aka NH3 and refrigerant name R-717) has long been considered a highly efficient workhorse in low-temperature, industrial refrigeration.

In recent decades, CO2 (refrigerant name R-744) has emerged as a leading environmentally friendly alternative in commercial applications. But before we get too accustomed to these familiar roles, the tables are starting to turn.

Today, manufacturers are developing new refrigeration technologies that blur the lines between these traditional applications.

Driven by sustainability objectives and regulatory compliance, these natural refrigerant technologies are converging into competing market spaces — where CO2 is becoming a viable option in industrial applications and low-charge ammonia systems are making inroads into commercial applications.

On the regulatory front, CO2 has the global hydrofluorocarbon (HFC) refrigerant phase-down to thank for gaining a foothold in commercial refrigeration.

As a natural alternative with near-zero global warming potential (GWP), it is one of the few ultra-low GWP refrigerants to be listed as acceptable by the Environmental Protection Agency’s (EPA) Significant New Alternatives Policy (SNAP).

CO2 has minimal safety or toxicity barriers to adoption with respect to building/fire codes or local authorities having jurisdiction (AHJ).

Be advised that in some regions, safety regulations are being developed to address piping best practices for managing CO2’s higher operating pressures.

On the other hand, ammonia has been the subject of increasing regulatory activity to address its potential toxicity concerns.

The Occupational Safety and Health Administration (OSHA) requires operators to provide necessary documentation for systems charged with 10,000 pounds of ammonia or more, according to its Process Safety Management of Highly Hazardous Chemicals standard.

Operators must always be prepared for rigorous inspections enforced by OSHA’s National Emphasis Program (NEP) on process safety management industries, which includes ammonia-based refrigeration facilities.

Since owners of large-charge ammonia systems have now incurred the added responsibility and expense of continuous record keeping, many operators are starting to re-evaluate these traditional ammonia refrigeration architectures.

To avoid possible regulatory entanglements and alleviate potential safety concerns, a new trend is emerging that favours lower-charge ammonia systems and moving the natural refrigerant out of occupied spaces. But even with these considerations, operators may still need the approval of local AHJs or secure the necessary permission to install ammonia systems.

Regardless of potential installation caveats, end users seeking to leave a smaller carbon footprint are formalizing sustainability strategies that include the following objectives:

Deploying low-GWP, future-proof refrigerants
Designing high energy-efficiency systems
Constructing “green” facilities

Natural refrigerants like CO2 and ammonia are helping businesses achieve these objectives.

Tale of the tape (comparing CO2 and NH3)

CO2 and ammonia are among the most eco-friendly, natural refrigerant alternatives available. OEMs continue to seek ways to exploit their efficiencies and mitigate their risks.

Ammonia
0 GWP and 0 ODP
Toxic and slightly flammable
Workhorse in cold storage, industrial refrigeration
Architectures now evolving to utilize lower charges used, preferably removed from occupied spaces
Extremely efficient in a wide range of temperatures

CO2
1 GWP and 0 ODP
High-pressure, low critical temperature, high triple point
Non-toxic, non-flammable; very minor leak threat
Foothold in commercial refrigeration as alternative to HFCs
Effectiveness in low temperatures making inroads in industrial applications

Winning combinations

Market dynamics are prompting both commercial and industrial operators to ask original equipment manufacturers (OEMs) which natural refrigerant options are available.

In turn, OEMs are responding with new innovations and system technologies that borrow from traditional architectures and cross over into competing market spaces. Let’s look at some innovations that are indicative of this convergence.

NH3/CO2 cascade — Ammonia in commercial refrigeration
Owners of large (+100-ton) commercial HFC systems are evaluating smaller, lower-charge NH3/CO2 cascade systems. Some industrial OEMs are expanding their product portfolios to target this emerging niche for natural, energy-efficient systems.

These NH3/CO2 cascade systems are designed to operate with very low charges of ammonia (100 pounds or less) on the high side of the refrigeration cycle (in a remote location, e.g., the roof) to chill the CO2. Chilled CO2 is then pumped into heat exchangers and sent to direct-expansion, low-temperature evaporators and CO2-rated compressors.

CO2 transcritical booster — CO2 in industrial refrigeration
CO2 represents a documentation-free refrigeration alternative to long-time owner/operators of large-charge ammonia systems; these operators are turning to commercial OEMs with CO2 expertise. CO2 transcritical booster systems have proved viable in cooler regions, relying on an architecture that utilizes several compressors in parallel to meet the desired cooling requirement. CO2 blast freezers are also effective in low temperatures, especially below -40 °F.

Smaller platform applications for ammonia

Both commercial and industrial operators with smaller facilities have many low-charge ammonia options to meet their cooling requirements and sustainability goals. Let’s look at a few of these systems:

NH3 low-charge centralized — this remote, distributed architecture is designed to reduce the liquid line length and subsequent refrigerant charge. The system utilizes a compressor skid in a smaller engine room and a liquid receiver located on the roof directly above the evaporators (liquid overfeed).

NH3 direct expansion — available in distributed or remote varieties, this system requires the circulation of much less refrigerant compared to the liquid overfeed method.

NH3 chiller with pumped CO2 secondary — here ammonia is used to chill CO2 (volatile brine), which is then pumped into the refrigerated areas.

NH3 chiller with pumped CO2 secondary, plus CO2 cascade — this system combines an NH3 chiller that provides the medium-temperature load via a CO2 secondary design, plus a CO2 cascade system for the low-temperature side.

Final round

It’s important to note that contracting companies are also being affected by this market convergence. Just as commercial operators are turning to industrial service technicians with ammonia expertise, industrial customers are calling on commercial mechanics to assist with their emerging CO2 applications.

Owner/operators of commercial and industrial facilities have much in common. Both must attempt to balance capital expenditures, total cost of ownership and sustainability objectives in their selection of refrigeration systems. But the blurring of lines between CO2 and ammonia technologies in these markets is ultimately beneficial to all involved.

While many of the options discussed herein are currently being “trialled” by some of the most forward-thinking companies, the fact remains that end users now have access to more environmentally friendly options than ever before.

This ongoing evolution will continue to drive OEM innovation to develop a greater diversity of options to meet end users’ specific requirements.
